Anterior Hemiepiphysiodesis of the Distal Tibia: A Step-by-step Surgical Technique Guide

Alan Katz1https://orcid.org/0000-0003-2466-2714, Évelyne Dumas2, Reggie Hamdy3

1,3Department of Pediatric Orthopedic Surgery, Limb Deformity Unit, Shriners Hospital for Children; Division of Orthopaedic Surgery, McGill University Health Centre, Montreal, Quebec, Canada

2Department of Orthopaedic Surgery, Centre Hospitalier de l’Université de Sherbrooke, Sherbrooke, Québec, Canada

Corresponding Author: Alan Katz, Department of Pediatric Orthopedic Surgery, Limb Deformity Unit, Shriners Hospital for Children; Division of Orthopaedic Surgery, McGill University Health Centre, Montreal, Quebec, Canada, Phone: +972 543470632, e-mail: ajkatz3@gmail.com

How to cite this article: Katz A, Dumas É, Hamdy R. Anterior Hemiepiphysiodesis of the Distal Tibia: A Step-by-step Surgical Technique Guide. Strategies Trauma Limb Reconstr 2023;18(3):174–180.

Source of support: Nil

Conflict of interest: None

Received on: 09 November 2023; Accepted on: 04 December 2023; Published on: 17 January 2024

ABSTRACT

Aim: This paper aims to serve as a guide for surgeons to prepare, execute, and perfect anterior hemiepiphysiodesis of the distal tibia (AHDT).

Background: Treatment of persistent or recurrent equinus deformity following multiple conservative and surgical interventions in patients with idiopathic clubfoot or neuromuscular conditions can be challenging, and multiple surgical options are presented in the existing literature. Anterior hemiepiphysiodesis of the distal tibia is an option that seems to be safe and efficient in treating this entity. To the best of our knowledge, there is not yet any detailed description of this surgical technique in the English literature.

Technique: The AHDT detailed surgical technique includes patient positioning, careful distal anterior tibial approach, placement of guided growth plates, fixation with epiphyseal and metaphyseal screws under fluoroscopic guidance, meticulous closure, and postoperative measures.

Conclusion: This guide can be used pre-operatively to plan the surgery, intra-operatively to aid in smooth and safe step progression, and post-operatively to assist in critical critiquing.

Clinical significance: By understanding the various stages of the surgery as well as the anatomy, pitfalls can be avoided and AHDT can be performed efficiently.

Keywords: Ankle, Clubfoot, Equines, Guided growth, Surgical anatomy, Tibia.

BACKGROUND

Persistent or recurrent equinus deformity in idiopathic clubfoot or in neuromuscular conditions following multiple conservative and/or surgical interventions is one of the most challenging obstacles for pediatric orthopedists. The ultimate goal of treatment is to have a functional, pain-free, plantigrade, mobile, and shoeable foot. Numerous surgical options have been presented in the literature, including revision of extensive posterior release, supra-malleolar osteotomy, talectomy, triple arthrodesis, and correction by external fixators. These options can have limited results, be technically challenging, or may carry significant risks. Additionally, some of these surgical interventions are associated with an increased risk of perioperative complications and prolonged recovery.1,2

Anterior hemiepiphysiodesis of the distal tibia (AHDT) is a newer option that improves dorsiflexion and has demonstrated positive results.3–5 It is indicated for pediatric clubfoot and neuromuscular condition patients with residual or recurrent equinus, open physeal plates, and who have substantial growth remaining. The principle behind AHDT originated from the extrapolation of treatment for flexion contracture of the knee.3,6–8 Little has been written on the topic and to the best of our knowledge, there is not yet any detailed description of this surgical technique in the English literature. We believe AHDT can be performed in a safe manner and be a very powerful tool in the arsenal of options for treating persistent or recurrent equinus.

This surgical technique article aims to describe the step-by-step procedure of AHDT. The relevant ankle anatomy encountered during AHDT is detailed and all steps are accompanied by clinical intraoperative photos and radiographs. The technique is written in a style based on a description of a recent case at our institution. This article will guide surgeons in a clear and precise fashion, with all the surgical specifics beginning from patient position and concluding with hospital discharge.

Technique

  1. Preparation

    1. The patient is placed in the supine position on the radiolucent operative table and preoperative prophylactic antibiotics were given.

    2. A “bump” is placed under the ipsilateral upper thigh and buttock and a leg elevator (example: bone foam) is placed under the surgical leg (Fig. 1).

      Fig. 1: Patient’s leg positioning, including leg elevator and tourniquet

    3. The fluoroscopic C-arm is positioned on the side of the surgical leg.

    4. A tourniquet is placed on the upper thigh.

    5. The patient is cleaned and draped in a sterile manner (Fig. 2).

      Fig. 2: Sterile draping

    6. Under fluoroscopy, the anatomical landmarks are identified and labelled with a surgical skin marker (the malleoli, the joint line, the physis, and the medial and lateral borders of the distal tibia) (Fig. 3).

      Figs 3A1 to D2: (A1 and A2) Marking the joint line. (A1) Clinical photo; (A2) Under fluoroscopy; (B1 and B2) Marking the physis. (B1) Clinical photo; (B2) Under fluoroscopy; (C1 and C2) Marking the medial border of the distal tibia. (C1) Clinical photo; (C2) Under fluoroscopy; (D1 and D2) Marking the lateral border of the distal tibia. (D1) Clinical photo; (D2) Under fluoroscopy

    7. The incision is marked, the midline between the medial and lateral borders of the distal tibia, centred on the physis, approximately 2.5 cm above and below the physis (Fig. 4).

      Fig. 4: Marking the incision

    8. The tourniquet is inflated after exsanguination of the limb with an esmark bandage.

  2. Approach

    1. A scalpel (#15 blade) is used to cut the skin in the midline of the distal anterior tibia according to the planned skin-marked incision (about 3–5 cm).

    2. Careful dissection of the subcutaneous soft tissues is carried out, taking care to protect the superficial peroneal nerve, passing from lateral to medial on the dorsal aspect of the foot.

    3. Exposure of the extensor retinaculum and anterior compartment fascia is performed, and a longitudinal incision in line with the skin incision, lateral to the anterior tibialis tendon, is made (Fig. 5).

      Fig. 5: Extensor retinaculum incision in line with skin incision, lateral to tibialis anterior tendon. Tibialis anterior tendon is exposed

    4. Relevant anatomy is then identified; tibialis anterior, the extensor hallucis longus, the extensor digitorum longus, as well as the neurovascular bundle lying between the extensor hallucis longus and extensor digitorum longus (Fig. 6).

      Fig. 6: Identification of tibialis anterior in self-retaining retractor and extensor hallucis longus (EHL) in hemostat. (Neurovascular bundle is lateral to EHL)

    5. With the use of retractors, the extensor hallucis longus and the neurovascular bundle are pulled laterally and the tibialis anterior medially.

    6. Incision of the fascia deep to the tibialis anterior tendon is made, to expose the distal tibia surface (Fig. 7A).

      Figs 7A and B: (A) Incision of the fascia deep to the tibialis anterior tendon; (B) Exposure of the anterior surface of distal tibia

    7. The surface of the distal tibia is gently cleared with a Cobb elevator, taking care not to enter the ankle joint or injure the periosteum (Fig. 7B).

  3. Plate placement

    1. Under fluoroscopic guidance, the guided growth plate on the distal anterior surface of the tibia is placed. The distal hole of the plate sits on the epiphysis, the proximal hole on the metaphysis, and the centred hole for the guiding pin lays over the physis. Attention is paid to being well-centred medial-lateral on the tibia (Fig. 8). [We use two 12 mm 2-holed plates side by side, as discussed in the “Discussion” section. We start first with the lateral plate and then the medial (Fig. 9).]

      Fig. 8: Positioning of the first 2-holed plate on the more lateral side of anterior distal tibia under fluoroscopy guidance. Note that the epiphyseal hole is entirely in the epiphysis, neither violating the joint nor the physis

      Fig. 9: Example of the “I” plate (4-holed) that is too large for this patient, with the screw hole overlapping with the physis

    2. The plate is secured with non-threaded K-wires in the centre of the plate going in the physis (Fig. 10).

      Figs 10A and B: (A) Securing plates with central k-wires in the physis; (B) Under fluoroscopic guidance making sure to be centred on the AP

    3. Under fluoroscopic guidance, k-wires are placed in the screw holes of the plate in the desired future screw location using the pin guide. A ball-tipped-wire-guide is used in the hole of the plate to aid in K-wire trajectory and placement. The proximal wire in metaphysis aims a little proximal to avoid the distal tibial physis that is oriented in a dome-like fashion. The distal wire in the epiphysis aims straight posteriorly, to avoid violating the physis proximal and the joint distal (Fig. 11).

      Fig. 11: Placing k-wires in plate holes guiding for screw placement. Note the plate is distalised to assure distal screw is entirely in the epiphysis, avoiding the physis

    4. The anterior cortex of the distal tibia is drilled in preparation for the screws, drilling only to breach the anterior cortex.

    5. Placement of the screws (3.5 mm cannulated) over the k-wires, slowly and alternately tightening in a balanced fashion (Fig. 12).

      Figs 12A and B: Screw placement over the k-wires. (A) Epiphyseal screw placement first, over k-wire; (B) Plate fixation with screws and k-wires out

    6. Attention to making sure that the screws do not violate the joint or the physis and that the plate is not compressed too tight on the periphery on the physis.

    7. The screws are placed in a parallel fashion and have strong purchase.

    8. (If a 2nd plate is used, as in our case) The same steps above are now repeated for the 2nd plate placement and fixation, with the k-wires placed parallel to the screws of the first plate (Figs 13 and 14).

      Fig. 13: K-wires placement for the second plate, parallel to the screws of the first plate

      Fig. 14: Plates fixated with screws

    9. Live view fluoroscopy is used to verify in full plantar flexion and full dorsiflexion that there is no impingement of the plate on the dorsal aspect of the talus (Fig. 15).

      Figs 15A and B: (A) Fluoroscopy in full plantar flexion; (B) Full dorsiflexion, making sure the plate does not impinge with full ROM

    10. A final fluoroscopy is performed (Fig. 16).

      Figs 16A and B: Final fluoroscopy (A) AP; (B) Lateral

  4. Closure

    1. Washout and irrigation are performed with saline.

    2. The fascia deep to the tibialis anterior tendon is sutured with size 0 absorbable sutures (Vicryl) over the plates to allow smooth gliding of the tendons over the anterior surface of the tibia (Fig. 17).

      Figs 17A to C: (A) Closure of the fascia deep to the tibialis anterior tendon over the plates; (B) The fascia closed; (C) Tendons in normal anatomical position over the deep fascia

    3. Extensor retinaculum is closed over the tendons with size 0 absorbable sutures (Fig. 18).

      Figs 18A and B: (A) Closure of extensor retinaculum over the tendons; (B) Extensor retinaculum closed

    4. Closure of the skin is performed with inverted deep subcutaneous simple stitches with 2-0 absorbable sutures and 4-0 absorbable subcuticular running stitches over it (Fig. 19).

      Fig. 19: Closure of the skin

    5. Steri-strips are placed on the wound.

    6. Local anaesthetic is given.

    7. The tourniquet is deflated and removed.

    8. Sterile bandages are placed on top of the Steri-strips.

    9. The patient’s ankle and foot are cast in a three-sided posterior cast.

    10. The patient is transferred to the PACU (Post-anaesthesia care Unit) in stable condition.

  5. Post-operation

    1. Patient is discharged the same day.

    2. Patient is informed of weight-bearing as tolerated.

    3. Follow up in the clinic at 1–2 weeks post-operation for wound check and removal of the cast.

    4. Follow up with X-rays at 3 months and then 6 months after to monitor the guided growth.
